Item description

Circuit board carving machine ZEE 340
Description
1.Usage: automatic line carving, drilling and milling edge for circuit board;
2.Maximum working size: 400mm×320mm;
3.Working mode: 2.5 d double-sided processing mode;
4.★Control handle is made up of ARM + FPGA of embedded control system, there is double USB interface in control handle, realizing master-slave USB communication model, that is, as the main USB device, directly read U disk data, as the slave USB device, communicate with the computer, which can completely work off the computer;
5.All module driving mode, three step motor modules + driving chip united to drive XYZ axis moving;
6.★Casting fuselage, Y axis moves driving beam arm move, in sculpture and drilling process, no displacement of circuit board;
7.Random configuration of processing data auxiliary processing software, data directly into the machine without any external software;
8.With function of X, Y, Z axis hardware and software limit;
9.High power spindle motor, higher processing precision, with memory function without electricity, no worries about outage;
10.★Handle human-computer interface: 128 * 64 dot matrix liquid crystal display + 18 multi-function keys, with simple and intuitive operation;
11.Processing precision: ±0.05mm;
12.Repeat precision: 0.01mm;
13.Minimum processing line width: 4mil; Minimum line gap 6 mil above;
14.Suitable milling cutter: 0.3mm~3.175mm Drilling handle: 3.175mm;
15.Suitable milling cutter: 1mm~3mm Cutter handle: 3.175mm;
16.Processing speed: 0~3m/min(actual-time adjustable);
17.Spindle motor: 800W frequency conversion motor The highest speed 60000 revolves/min;
18.Step motor: 35W four phase step motor*3;
19.Shaft driving mode: entire advanceding screw driving;
20.★With mating PC control software, lifetime free upgrades;
21.Spindle movements itinerary: 60mm;
22.Working power: AC220V/50Hz 1000W;
23.Overall dimension: main engine: 620mm×750mm×500mm;
Control cabinet: 200mm×300mm×550mm;
24.Net weight: 105KG.
